High Brightness Output
Strong beam performance for long-distance projection and high-impact stage looks.
Enter keywords to search products
Enter keywords to search products
Voltage: AC100 ~ 240 v50/60 hz
Power: 800w
Light source: high power 700w LED module, CCT:7000K
CRI:≥90,High CRI mode: up to 95,R9 up to 95
Pan& tilt: Pan 540°/630°，Tilt 270°(16bit precision scan)
Spot uniformity: 90%
Color system: CMY+CTO mixed color system
Color wheel: 10 colors + white, half color effect, can be arbitrarily positioned, with bi-directional rotating rainbow effect;
Static Gobo wheel: 10 pluggable fixed gobos+white;
Rotating Gobo wheel: 7 pluggable rotating Gobo+white, with jitter and arbitrary positioning function;
1 dynamic effect wheel effect;
Prism: 4 prism, 4 row prism, with bidirectional rotation, macro function, prism can be overlay and positioning.
Cutting Wheel: a controllable spot Cutting system composed of 4 Cutting pieces, can be 180°rotation.
Atomization: Light atomization, heavy atomization
Dimming: 0~100% linear dimming
Aperture : 5~100% linear adjustment
Strobe: up to 25Hz/s, random and pulse stroboscopic
Zoom : 4.5°~50°with automatic zoom in and out
Control: DMX512/auto-run/master-slave/sound, with RDM function
Channel: 36/40/65 international standard DMX512 Channels
Display: colorful LCD touch screen with RDM function.
Feature: Input signal isolation protection function;High temperature automatic protection;RDM function.
Product size: 40x27.5x70mm
Package size: 71.5x55.5x49.5mm
N.W: 26.3kgs
SKU：AK800
See The Power of Light
Effect:
Video:
Strong beam performance for long-distance projection and high-impact stage looks.
Carefully matched lens, color and gobo components help deliver clear effects.
DMX control modes support flexible programming for events and installations.
Quick sample preparation and project communication for urgent lighting needs.
Support custom logo, packaging, product function matching and project-based stage lighting solutions for distributors, rental companies and engineering projects.
Custom logo, label and packaging options for distributors.
Lighting functions can be matched to project and market requirements.
Support for product selection, samples, specification confirmation and delivery.
No middleman cost
100% strict testing
15+ years experience
OEM / ODM available
3-7 days for sample
1000+ successful cases
A high-output beam moving head with narrow beam angle, fast movement, rich gobos, and prism effects is ideal for nightclub shows.
Beam lights create tight aerial beams, BSW fixtures combine beam, spot and wash functions, while profile lights offer precise framing and projection control.
Yes. Logo, housing color, packaging, lens options and lighting function customization can be discussed based on order quantity.
Sample orders are usually prepared in 3-7 days. Bulk order lead time depends on quantity and customization requirements.
Most professional fixtures support DMX512, RDM, master-slave, auto mode and sound mode. Please check the exact model specification.
The standard warranty is 2 years unless otherwise stated on the quotation or product agreement.
