See The Power of Light
The JC LIGHT AK500 / AK600 / AK700 is a high-end LED profile moving head light designed for concerts, theatre productions and large-scale stage applications. Featuring a powerful LED module with high CRI performance, it delivers exceptional brightness, color accuracy and precision beam shaping.
Equipped with CMY+CTO color mixing, dual gobo wheels, dynamic effects and a professional framing system, this fixture provides advanced lighting control for creative stage design. Its wide zoom range and high-definition optics ensure versatile performance across various environments.
| Model | LED Power | Total Power |
|---|---|---|
| AK500 | 500W LED | 600W |
| AK600 | 600W LED | 700W |
| AK700 | 700W LED | 800W |
| Voltage | AC100-240V, 50/60Hz |
| Color Temperature | 7000K |
| CRI | ≥90 (up to 95) |
| Zoom | 4.5° – 50° |
| Focus | Automatic focusing |
| Color System | CMY + CTO color mixing |
| Color Wheel | 6 colors + white |
| Static Gobo | 7 replaceable gobos + white |
| Rotating Gobo | 7 rotating gobos + white |
| Effect Wheel | 1 dynamic effect wheel |
| Prism | 16 prism, 8-row prism (overlay and rotation) |
| Frost | Light frost and heavy frost |
| Strobe | 1–25Hz with random and pulse modes |
| Dimming | 0–100% linear dimming |
| Optical Iris | 5–100% linear adjustment |
| Framing System | 4-blade cutting system with 90° rotation |
| Pan / Tilt | 540°/630° Pan, 270° Tilt (16-bit) |
| Control Mode | DMX512 / Auto / Master-slave / Sound / RDM |
| Channel | 28CH / 37CH |
| Display | LCD display |
| Product Size | 372 × 290 × 683 mm |
| Package Size | 740 × 355 × 455 mm |
| Net Weight | 22.5 kg |
| Gross Weight | 24.0 kg |
| SKU | AK500 / AK600 / AK700 |
The difference is the LED power and brightness level, suitable for different stage sizes and applications.
Yes. It features a 4-blade framing system for precise beam shaping.
Yes. With high CRI and CMY color mixing, it is ideal for theatre and broadcast lighting.
It supports gobo, prism, zoom, frost, strobe and dynamic effects.
Yes. It supports RDM for remote addressing and monitoring.
Yes. JC LIGHT provides OEM and ODM services, including branding and product customization.
Need a quick quotation? Contact us with your requirements and quantity. We will provide fast pricing and suitable lighting solutions.
Strong beam performance for long-distance projection and high-impact stage looks.
Carefully matched lens, color and gobo components help deliver clear effects.
DMX control modes support flexible programming for events and installations.
Quick sample preparation and project communication for urgent lighting needs.
Support custom logo, packaging, product function matching and project-based stage lighting solutions for distributors, rental companies and engineering projects.
Custom logo, label and packaging options for distributors.
Lighting functions can be matched to project and market requirements.
Support for product selection, samples, specification confirmation and delivery.
No middleman cost
100% strict testing
15+ years experience
OEM / ODM available
3-7 days for sample
1000+ successful cases
A high-output beam moving head with narrow beam angle, fast movement, rich gobos, and prism effects is ideal for nightclub shows.
Beam lights create tight aerial beams, BSW fixtures combine beam, spot and wash functions, while profile lights offer precise framing and projection control.
Yes. Logo, housing color, packaging, lens options and lighting function customization can be discussed based on order quantity.
Sample orders are usually prepared in 3-7 days. Bulk order lead time depends on quantity and customization requirements.
Most professional fixtures support DMX512, RDM, master-slave, auto mode and sound mode. Please check the exact model specification.
The standard warranty is 2 years unless otherwise stated on the quotation or product agreement.
