See The Power of Light
The JC LIGHT F18X/F24X LED linear bar light is a high-performance outdoor fixture designed for stage, architectural and event lighting. Available in 18 or 24 high-power RGBW LEDs, it delivers strong brightness, precise beam control and dynamic pixel effects for professional lighting applications.
Featuring an IP66 waterproof design and a unique square lens optical system, this linear light provides uniform output and flexible beam angles. With multiple installation options and splice capability, it is ideal for large-scale lighting projects, building facades and stage designs.
| Voltage | AC100-240V, 50/60Hz |
| Power | 400W / 500W |
| Light Source | 18pcs / 24pcs × 20W RGBW LED |
| Beam Angle | 6° / 10° / 20° / 40° |
| Optical System | Square lens optical design |
| Control Panel | OLED display + 4 touch keys |
| Control Protocol | DMX512 / RDM |
| Channel Mode | Multiple modes |
| Control Channels | 4 / 6 / 9 / 72 / 74CH |
| Software Upgrade | Supported via DMX |
| Installation | Horizontal / Vertical / Spliceable |
| Accessories | Splicing joints, frost filter, barn doors, vertical brackets (optional) |
| Protection Rating | IP66 |
| Product Size | 1020 × 106 × 277 mm |
| Net Weight | 9.5 kg |
| SKU | F18X / F24X |
Yes. With IP66 waterproof protection, it is suitable for outdoor architectural lighting, stage setups and event installations.
The fixture supports 6°, 10°, 20° and 40° beam angles, allowing flexible use for different lighting applications.
Yes. The light supports pixel control, enabling dynamic lighting effects and advanced programming.
Yes. The fixture supports left and right splicing, allowing multiple units to be combined for large-scale installations.
Yes. It supports DMX512 and RDM, making it compatible with professional lighting consoles.
Yes. JC LIGHT provides OEM and ODM services, including branding, packaging and configuration customization.
