See The Power of Light
The JC LIGHT Y480 / Y480S (A19) is a professional 20R beam moving head designed for concerts, stage lighting and large-scale event applications. Featuring high-performance USHIO 420W or Osram 480W lamps, it delivers ultra-bright beams, sharp projection and dynamic lighting effects.
Equipped with advanced color mixing, multiple prism combinations and precise motor control, this fixture offers powerful beam performance and flexible programming for professional lighting designers.
| Model | Light Source |
|---|---|
| Y480 | 420W USHIO lamp |
| Y480S | 480W Osram lamp |
| Voltage | AC110-240V, 50/60Hz |
| Power Consumption | 600W |
| Motor | Three-phase motor |
| Color Wheel | 13 colors + white |
| Gobo Wheel | 17 gobos + white |
| Prism | 8+16 prism, 8+16+24 prism (overlay and rotation) |
| Focus | Electronic focus |
| Frost | 0–99% linear frost effect |
| Dimming | 0–100% linear dimming |
| Strobe | 1–13Hz |
| Pan / Tilt | 540° / 270° (16-bit precision) |
| Control Mode | DMX512 / Master-slave / Auto / Sound |
| Channel | 16CH / 20CH |
| IP Rating | IP20 (indoor use) |
| Model | A19 |
| SKU | Y480 / Y480S |
The difference lies in the lamp type and brightness: Y480 uses a 420W USHIO lamp, while Y480S uses a 480W Osram lamp.
It supports beam, gobo, prism, frost and strobe effects for dynamic stage lighting.
Yes. It supports multiple prism overlays (8, 16, 24 facets) with rotation and positioning.
Yes. Its high brightness makes it ideal for concerts and large stage applications.
Yes. It supports DMX512 along with auto, sound and master-slave modes.
Yes. JC LIGHT provides OEM and ODM services, including branding and product customization.
Need a quick quotation? Contact us with your requirements and quantity. We will provide fast pricing and suitable lighting solutions.
Strong beam performance for long-distance projection and high-impact stage looks.
Carefully matched lens, color and gobo components help deliver clear effects.
DMX control modes support flexible programming for events and installations.
Quick sample preparation and project communication for urgent lighting needs.
Support custom logo, packaging, product function matching and project-based stage lighting solutions for distributors, rental companies and engineering projects.
Custom logo, label and packaging options for distributors.
Lighting functions can be matched to project and market requirements.
Support for product selection, samples, specification confirmation and delivery.
No middleman cost
100% strict testing
15+ years experience
OEM / ODM available
3-7 days for sample
1000+ successful cases
A high-output beam moving head with narrow beam angle, fast movement, rich gobos, and prism effects is ideal for nightclub shows.
Beam lights create tight aerial beams, BSW fixtures combine beam, spot and wash functions, while profile lights offer precise framing and projection control.
Yes. Logo, housing color, packaging, lens options and lighting function customization can be discussed based on order quantity.
Sample orders are usually prepared in 3-7 days. Bulk order lead time depends on quantity and customization requirements.
Most professional fixtures support DMX512, RDM, master-slave, auto mode and sound mode. Please check the exact model specification.
The standard warranty is 2 years unless otherwise stated on the quotation or product agreement.
