See The Power of Light
The JC LIGHT ZL380A (A16) “Wolf Warriors” is a professional 18R beam moving head designed for stage, concert and large-scale lighting applications. Equipped with a high-performance 380W discharge lamp, it delivers ultra-narrow and powerful beam effects with outstanding brightness and long-distance projection.
Featuring a large optical lens, dual prism system and advanced focusing technology, this fixture creates sharp beams and dynamic layered effects. Its durable structure and intelligent cooling system ensure reliable performance for continuous operation in demanding environments.
| Light Source | 380W discharge lamp (YODN / Philips / Osram) |
| Lamp Lifespan | 3000 hours |
| Optics | 165mm large diameter lens |
| Beam Angle | 1.8° |
| Color Wheel | 13 colors + white |
| Gobo Wheel | 13 static gobos + open |
| Prism | 8 prism, 8+16+24 prism combinations, rotation and overlay |
| Focus | Electronic linear HD focusing |
| Frost | 0–100% linear frost effect |
| Dimming | 0–100% linear dimming |
| Strobe | High-speed strobe effect |
| Display | LCD screen |
| Movement | XY axis three-phase motor |
| Control Mode | DMX512 / Auto / Master-slave / Sound / RDM |
| Channel | 16CH / 20CH |
| Voltage | AC110-240V, 50/60Hz |
| Power | 450W |
| Material | Engineering nylon + die-cast aluminum |
| IP Rating | IP20 (indoor use) |
| Product Size | 376 × 270 × 617 mm |
| Package Size | 480 × 420 × 590 mm |
| Net Weight | 19 kg |
| Gross Weight | 22 kg |
| Model | A16 |
| SKU | ZL380A |
It features a 1.8° ultra-narrow beam and high brightness output, ideal for long-distance projection.
It includes multiple prism combinations (8, 16, 24 facets) that can rotate and overlap.
Yes. It supports RDM two-way communication for remote configuration.
Yes. Its durable construction and stable performance make it suitable for rental and touring applications.
With IP20 rating, it is designed for indoor stage and event environments.
Yes. JC LIGHT provides OEM and ODM services, including branding and product customization.
Need a quick quotation? Contact us with your requirements and quantity. We will provide fast pricing and suitable lighting solutions.
Effect:
Video:
Strong beam performance for long-distance projection and high-impact stage looks.
Carefully matched lens, color and gobo components help deliver clear effects.
DMX control modes support flexible programming for events and installations.
Quick sample preparation and project communication for urgent lighting needs.
Support custom logo, packaging, product function matching and project-based stage lighting solutions for distributors, rental companies and engineering projects.
Custom logo, label and packaging options for distributors.
Lighting functions can be matched to project and market requirements.
Support for product selection, samples, specification confirmation and delivery.
No middleman cost
100% strict testing
15+ years experience
OEM / ODM available
3-7 days for sample
1000+ successful cases
A high-output beam moving head with narrow beam angle, fast movement, rich gobos, and prism effects is ideal for nightclub shows.
Beam lights create tight aerial beams, BSW fixtures combine beam, spot and wash functions, while profile lights offer precise framing and projection control.
Yes. Logo, housing color, packaging, lens options and lighting function customization can be discussed based on order quantity.
Sample orders are usually prepared in 3-7 days. Bulk order lead time depends on quantity and customization requirements.
Most professional fixtures support DMX512, RDM, master-slave, auto mode and sound mode. Please check the exact model specification.
The standard warranty is 2 years unless otherwise stated on the quotation or product agreement.
