See The Power of Light
The JC LIGHT AK4 / AK5 / AK6 is a professional LED profile moving head light designed for theatre, stage and high-end event lighting. Featuring a high-brightness LED module and advanced optical system, it delivers powerful output, precise beam shaping and excellent color performance.
Equipped with CMY+CTO color mixing, dual gobo wheels, dynamic effects and a 4-blade framing system, this fixture provides full creative control for professional lighting designers. Its high CRI ensures accurate color reproduction, making it ideal for broadcast and stage applications.
| Model | LED Power | Total Power |
|---|---|---|
| AK4 | 400W LED | 500W |
| AK5 | 500W LED | 600W |
| AK6 | 600W LED | 700W |
| Voltage | AC100-240V, 50/60Hz |
| CRI | ≥90 (up to 95, R9 up to 95) |
| Zoom | 4.5° – 35° |
| Focus | Linear focusing |
| Color System | CMY + CTO color mixing |
| Color Wheel | 7 colors + white |
| Static Gobo | 8 fixed gobos + white |
| Rotating Gobo | 7 rotating gobos + white |
| Effect Wheel | Dynamic flame and water effects |
| Prism | 3-facet prism, 8-facet prism |
| Frost | Light and heavy frost |
| Aperture | 5–100% adjustable |
| Dimming | 0–100% linear dimming |
| Strobe | Up to 25Hz |
| Framing System | 4-blade cutting system with 90° rotation |
| Pan / Tilt | 540° / 270° (16-bit precision) |
| Control Mode | DMX512 / Auto / Master-slave / Sound / RDM |
| Channel | 22CH / 26CH |
| IP Rating | IP20 (indoor use) |
| Product Size | 621 × 315 × 263 mm |
| Net Weight | 16.65 kg |
| SKU | AK4 / AK5 / AK6 |
The difference is the LED power and brightness level, suitable for different stage sizes and applications.
Yes. It includes a 4-blade framing system for precise beam shaping.
Yes. With high CRI up to 95, it is ideal for theatre and TV production.
It supports gobo, prism, zoom, frost, strobe and dynamic effects.
Yes. It supports RDM for remote configuration and monitoring.
Yes. JC LIGHT provides OEM and ODM services, including branding and product customization.
