High Brightness Output
Strong beam performance for long-distance projection and high-impact stage looks.
Enter keywords to search products
Enter keywords to search products
Wide Voltage: 110V-240V 50-60Hz
Power: 400W / 480W/ 580W
Light source: 380W/420W/461W USHIO lamp, lifespan: 3000-5000h
Color wheel: 13 colors+ white, colorful rainbow effect + atomization function
Gobo wheel: 14 fixed gobo + open, 9 rotating gobo (customized logo, Patterns can be infinite zoom in and out linearly)
Rotating gobo wheel diameter: 13.5mm, effective inner diameter : 12mm
Prism: 8 prism, overlay can be rotated, macro function
Effect wheel: can rotate a circular 8 prism
Strobe: support mechanical stroboscopic and adjustable stroboscopic effect, support strobe macro function.
Dimming: 0%-100% linear dimming
Beam Angle : 2.8~38°
XY motor: Three electric drive, powerful, faster, more stable, more silent
Control mode : DMX512/auto-run/master slave/sound
Channels: 17CH
Display: LCD display
Material: die casting magnesium alloy
Horizontal/Vertical: 540° horizontal or 270° vertical scanning(8/16 bits)
IP rating: IP67
Product size: 550*440*680mm
Package size: 600*500*850mm
Net weight: 28Kg
Gross weight: 36KG
Appearance: Full waterproof, UV resistant, high temperature resistant, aging resistant + high temperature resistant die-cast aluminum shell, light volume, using wind drainage and temperature intelligent monitoring technology, fast heat dissipation!
Feature:
◎smart automatic error correction reset function.
◎horizontal and vertical locking button, maintenance and handling more convenient.
◎Excellent fan drive performance with extremely low noise.
◎small shape, huge energy, thickness beam
SKU：F380A/F480A/F580A；LED Version：F400A/F500A
See The Power of Light
Strong beam performance for long-distance projection and high-impact stage looks.
Carefully matched lens, color and gobo components help deliver clear effects.
DMX control modes support flexible programming for events and installations.
Quick sample preparation and project communication for urgent lighting needs.
Support custom logo, packaging, product function matching and project-based stage lighting solutions for distributors, rental companies and engineering projects.
Custom logo, label and packaging options for distributors.
Lighting functions can be matched to project and market requirements.
Support for product selection, samples, specification confirmation and delivery.
No middleman cost
100% strict testing
15+ years experience
OEM / ODM available
3-7 days for sample
1000+ successful cases
A high-output beam moving head with narrow beam angle, fast movement, rich gobos, and prism effects is ideal for nightclub shows.
Beam lights create tight aerial beams, BSW fixtures combine beam, spot and wash functions, while profile lights offer precise framing and projection control.
Yes. Logo, housing color, packaging, lens options and lighting function customization can be discussed based on order quantity.
Sample orders are usually prepared in 3-7 days. Bulk order lead time depends on quantity and customization requirements.
Most professional fixtures support DMX512, RDM, master-slave, auto mode and sound mode. Please check the exact model specification.
The standard warranty is 2 years unless otherwise stated on the quotation or product agreement.
